Technical Details
- Keyboard Architecture: Frameless, low-profile chiclet design.
- Tactile Mechanism: Individual scissor-switch keys tuned for silent, high-speed typing.
- Interface: Precision-molded flexible ribbon cable with high-density contacts.
- Keycap Material: Specialized ABS polymer with a matte anti-glare finish for long-term legend clarity.
- Design Intent: Designed specifically for the EliteBook 1040 G4 and compatible x360 convertible chassis.
- Illumination: Non-Backlit
Comprehensive Hardware Compatibility
This input keyboard is functionally compatible with several premium HP business laptops. While the following product codes are provided to assist with search and reference, manufacture internal motherboard revisions can vary by region.
The most secure way to ensure your repair is successful on the first attempt is to verify compatibility with us first, our team is trained to spot the subtle differences in ribbon designs.
Compatible Device Families:
- HP EliteBook Series: 1040 G4
- HP EliteBook x360 Series: 1040 G4, 1040 G5, 1040 G6
Technical Spare Part (P/N) Cross-Reference:
L02267-001, L02268-001, 2H-BAZUKI64312, L02267-041.
Overcoming Compatibility Friction
We understand that the primary fear when sourcing internal laptop parts is the risk of an “almost-fit.” A slightly different ribbon angle or a misplaced mounting screw can halt a repair in its tracks.
To solve this, we offer a Pre-Sale Validation Service. Simply send us a quick digital image of your current keyboard’s underside or its part number sticker, and we will cross-reference it against our inventory for a 100% mechanical match. You can do this by clicking the “verify compatibility” button.
If you choose to purchase without verification and find that the unit doesn’t interface perfectly with your 1040 G4’s top cover, you are fully protected. We provide a 7-day return and exchange for all fitment-related issues (subject to policy).
Professional Installation & Usage Guide
Is this keyboard difficult to swap?
The EliteBook 1040 G4 is a precision-engineered replacement. As a “frameless” keyboard, it requires the removal of several internal components to access the mounting points from the underside of the palm rest. We recommend professional installation for users who are not comfortable with deep chassis disassembly (in case you do not have access to any, we can recommend a few qualified technicians).
Can I install this non-backlit unit if my laptop was originally backlit?
Yes, it will seat into the chassis perfectly and all typing functions will be identical.
How do I protect the keys during daily travel?
Since the 1040 G4 is often used as a mobile workhorse, we suggest using a thin microfiber sheet between the keyboard and screen when the lid is closed to prevent long-term friction marks on the display glass.
